United Water

Location Tongxiang, China
Sector Infrastructure
Material Aubrick
Application Walls, paving

At a water treatment works in Tongxiang, China, 200,000 Aubrick bricks have been used across the site: in the wall panels of every treatment building, the paving between them, and the boundary wall along the road.

200,000
Bricks
35.6 tonnes
CO₂ absorbed
432 tonnes
Soil and sand
Water treatment works in Tongxiang seen from the road, with grey Aubrick wall panels in cream concrete frames

Aubrick is our carbon negative earth brick, made by our partner earth4Earth from excavated soil that would otherwise go to landfill, set with a lime binder and compressed rather than fired. Here it fills the panels of each building's concrete frame, from ground level to the roof.

Treatment building with an external stair and grey Aubrick wall panels, beside open treatment tanks
External stair and paving beside a grey Aubrick wall
Tall treatment building clad in grey Aubrick panels between cream frame columns
Grey Aubrick wall panels in a cream concrete frame
Treatment building with a white scrubber tower, yellow access ladder, and grey Aubrick wall panels
Yellow access ladder and a window set into a grey Aubrick wall

The lime in each brick absorbs carbon dioxide from the air, up to 178g per brick, and holds what it takes in. Across 200,000 bricks, that is up to 35.6 tonnes of CO₂.

Two treatment buildings with grey Aubrick wall panels and a lattice tower
Aubrick-clad treatment building behind the pipework over the treatment tanks

The same brick is laid as paving between the buildings, edged with bricks set on end, and as a perforated boundary wall with solid piers.

Perforated grey Aubrick boundary wall with solid brick piers along a road
Grey Aubrick paving laid in herringbone, edged with bricks set on end

It is the same brick we supply in the UK as Aubrick, UKCA and CE marked, with a published EPD. At the end of its life it can be crushed and used in new bricks, or returned to the ground as soil.

Photographer LCI
